1. (power)/Volume knob and
2.
3. BAND(band) button
5. (pause/play), Preset station1 button
6. INT (intro) 2 button
7. RPT (repeat) 3 button
8. RDM (random) 4 button
9. -10(previous 10 tracks) 5 button
10. +10(next 10 tracks) 6 button
11. CLOCK (clock setting) button, (end call) button
12. (tune down, seek down, previous track, fast reverse) button
13. (tune up, seek up, next track, fast forward)button
14. MUTE button
15.
SEL (select/menu) button
MODE (source) button
, (anser call) button
4. AMS (automatic store / preset station scan, automatic music search) button
, Preset station
, Preset station
, Preset station
, DIR-(previous folder), Preset station
, DIR+(next folder), Preset station
(eject) button
16. Disc slot
17. IR remote sensor
18. LCD Display
19. Sliding door for USB port
20. USB Port
21. Sliding door for AUX IN jack
22. AUX IN (auxiliary input) jack
4
Remove panel
23. Hands-free Microphone
24. Front panel release button
25. SD Card Slot
26. Reset button
25
26
