Pin Name
Pin Number
Signal or Label
Comment
PE13
T10
SDRAM_D10
-
PE14
U10
SDRAM_D1
1
-
PE15
R1
1
SDRAM_D12
-
PF0
G4
SDRAM_A0
-
PF1
G3
SDRAM_A1
-
PF2
G1
SDRAM_A2
-
PF3
H4
SDRAM_A3
-
PF4
J5
SDRAM_A4
-
PF5
J4
SDRAM_A5
-
PF6
K2
QSPI_BK1_IO3
-
PF7
K3
QSPI_BK1_IO2
-
PF8
K4
ARD_A1
-
PF9
L4
QSPI_BK1_IO1
-
PF10
L3
QSPI_CLK
-
PF1
1
T7
SDRAM_SDNRAS
-
PF12
R7
SDRAM_A6
-
PF13
P7
SDRAM_A7
-
PF14
P8
SDRAM_A8
-
PF15
R9
SDRAM_A9
-
PG0
T8
SDRAM_A10
-
PG1
U8
SDRAM_A1
1
-
PG2
H16
LCD_INT
-
PG3
H15
ARD_D2
-
PG4
H14
SDRAM_BA0
-
PG5
G14
SDRAM_BA1
-
PG6
G15
RCC_OSC_OUT
-
PG7
F16
Audio_Int
-
PG8
F15
SDRAM_SDCLK
-
PG9
A10
QSPI_BK2_IO2
-
PG10
A9
SAI2_SDB
-
PG1
1
B9
MII_TX_EN
-
PG12
C9
MII_TXD1
-
PG13
D9
MII_TXD0
-
PG14
D8
QSPI_BK2_IO3
-
PG15
D6
SDRAM_SDNCAS
-
PH0
J2
OSC_25M
-
PH1
J1
STMOD#17
-
PH2
N2
QSPI_BK2_IO0||MII_CRS
-
PH3
P2
QSPI_BK2_IO1||MII_COL
-
PH4
P3
STMOD#19
-
UM2488
STM32H745I-DISCO and STM32H750B-DK I/O assignment
