Pin Name
Pin Number
Signal or Label
Comment
PH5
P4
SDRAM_SDNWE
-
PH6
T1
1
SDRAM_SDNE1
-
PH7
U13
SDRAM_SDCKE1
-
PH8
T13
STMOD#20
-
PH9
R13
LCD_R3
-
PH10
P13
STMOD#12-RST
-
PH1
1
P14
OTG_FS2_Overcurrent
-
PH12
R14
STMOD#1
1-INT
-
PH13
D16
FDCAN1_TX
-
PH14
B17
FDCAN1_RX
-
PH15
PF6
ARD_D9
-
PI0
A16
LCD_G5
-
PI1
A15
LCD_G6
-
PI2
B15
ARD_D12
-
PI3
C14
STMOD#8-MOSIs
-
PI4
A4
SAI2_MCLKA
-
PI5
A3
SAI2_SCKA
-
PI6
A2
SAI2_SDA
-
PI7
B3
SAI2_FSA
-
PI8
E4
ARD_D7
-
PI9
E2
LCD_VSYNC
-
PI10
F3
MII_RX_ER
-
PI1
1
F4
STMOD#18
-
PI12
H1
LCD_HSYNC
-
PI13
H2
LED2
-
PI14
H3
LCD_CLK
-
PI15
P5
LCD_R0
-
PJ0
N6
LCD_R1
-
PJ1
P6
LCD_R2
-
PJ2
T6
LED1
-
PJ3
U6
LCD_R4
-
PJ4
U7
LCD_R5
-
PJ5
R12
LCD_R6
-
PJ6
N15
LCD_R7
-
PJ7
N14
LCD_G0
-
PJ8
N13
LCD_G1
-
PJ9
M14
LCD_G2
-
PJ10
L14
LCD_G3
-
PJ1
1
K14
LCD_G4
-
PJ12
D1
1
LCD_B0
-
UM2488
STM32H745I-DISCO and STM32H750B-DK I/O assignment
UM2488
-
Rev 4
page 25/55
24
26
Table of Contents
1 Features
2
Table 1. List of Available Products
3
Table 2. Codification Explanation
3
2 Ordering Information
3
Product Marking
3
Codification
3
3 Development Environment
4
System Requirements
4
Development Toolchains
4
Demonstration Software
4
Table 3. ON/OFF Convention
5
4 Conventions
5
5 Delivery Recommendations
6
6 Hardware Layout and Configuration
7
STM32H753I-EVAL Evaluation Board Layout
7
Embedded ST_LINK/V2-1
10
STM32H753I-EVAL Evaluation Board Mechanical Drawing
10
Power Supply
11
Table 4. Power-Supply Related Jumper and Solder Bridge Settings
12
Clock Sources
13
Reset Sources
13
Audio
14
Emmc
14
Ethernet
14
Power over Ethernet
14
Sdram
14
Usb Otg_Fs
14
Buttons and Leds
15
Quad-SPI nor Flash Memory
15
RGB LCD Display
15
Table 5. Assignment of Control Ports to LED
15
Virtual COM Port
15
Table 6. ARDUINO ® Connectors (CN2, CN3, CN6, and CN7)
16
CN1 Ethernet RJ45 Connector
17
CN13 USB OTG_FS Micro-AB Connector
17
7 Connectors
16
ARDUINO ® uno V3 Connectors
16
Table 8. CN1 Ethernet RJ45 Connector
17
Table 7. CN13 USB OTGFS Micro-AB Connector
17
Table 10. CN2 Stmod+ Connector
19
Table 11. CN14 USB Type-B Connector
19
CN16 TAG Connector
20
CN4 STDC14 Connector
20
CN8 Audio Line Input (Blue Jack) Connector
20
Table 12. CN16 TAG Connector
20
Table 13. STDC14 Connector
20
CN15 USB Power Connector
21
Table 9. LCD RGB Connector
18
Audio Stereo Speaker Header Connectors (CN17 and CN18)
19
CN14 STLINK-V3 USB Micro-B Connector
19
CN2 Stmod+ Connector
19
CN9 Audio Line Output (Green Jack) Connector
19
LCD RGB Connector
18
Table 14. CN15 USB Micro-B Connector
21
8 STM32H745I-DISCO and STM32H750B-DK I/O Assignment
22
Table 15. STM32H745I-DISCO and STM32H750B-DK I/O Assignment
22
9 Electrical Schematics
29
Appendix A Federal Communications Commission (FCC) and Industry Canada (IC)
49
Compliance Statements
49
FCC Compliance Statement
49
IC Compliance Statement
49
Table 16. Document Revision History
50
Table of Contents
51
Revision History
50
Contents
51
List of Tables
53
List of Figures
54
