11
Key
No. Description Qty. HRPB20 HRPB24 HRPB30
1 Sta-Rite Logo 1 32145-4001 32145-4001 32145-4001
2
Model Label
1 32155-4028 32155-4029 32155-4030
3 NSF Seal 1 Not Available Not Available Not Available
4 O-Ring* 1 35505-1317 35505-1317 35505-1317
5 Fill Cap Assembly 1 24750-0065 24750-0065 24750-0065
6 Pressure Gauge* 1 33600-0023T 33600-0023T 33600-0023T
7 Air Release Valve* 1 U212-252D U212-252D U212-252D
8 Decal:
“WARNING: Turn Off Pump...”
1 WC27-23 WC27-23 WC27-23
9 Upper Shell 1 WC31-253P WC31-251P WC31-255P
10 Bolt,
3
⁄8-16x2
1
⁄4”24U30-884ZP – –
10 Bolt,
1
⁄2-13x2
1
⁄2”24– U30-91C –
10 Bolt,
1
⁄
2-13x2
3
⁄
4”32– – U30-901ZP
11 Washer, Flat
3
⁄8”48U43-62ZP – –
11 Washer, Flat
1
⁄2”48– U43-129ZP –
11 Washer, Flat
1
⁄2”64– – U43-129ZP
12 Internal Assembly (Kit) 1 WC237-514P 24751-0110 24752-0110
12A Air Bleed Filter 1 WC8-126 WC8-126 WC8-126
12B Tube 1 WC37-384P WC37-384P WC37-384P
12C Compression Elbow 1 WC78-84P WC78-84P WC78-84P
12D Lateral - Short 4 24735-0011 – –
12E Lateral - Long 12 24600-0003 – –
12E Lateral - Long 16 – 24700-0075 24700-0075
12F Tank Fitting Assembly 2 WC178-93P 24751-0010 24751-0010
13 Quad Ring 2 35515-1296 35515-1296 35515-1296
14 Lower Shell† 1 WC31-252P WC31-250P WC31-254P
15 Nut,
3
⁄8-16 24 U36-38C – –
15 Nut,
1
⁄2-13 24 – U36-39C –
15 Nut,
1
⁄2-13 32 – – U36-39C
16 Tape 2 37685-0006A 37685-0006A 37685-0006A
17 Base 1 23900-0105 23901-0005 23901-0005
18 Plug, 1/4” 1 WC78-40T WC78-40T WC78-40T
19 Drain Plug Sub-Assembly 1 24700-0411 24700-0411 24700-0411
20 O-Ring 1 U9-269 U9-269 U9-269
21 Union Adapter 2 U11-198P U11-198P U11-198P
22 Fitting Nut, 2” 2 24752-0049 24752-0049 24752-0049
23 Inlet - Outlet Label 1 32155-4004 32155-4004 32155-4004
24 Cord Ring 1 24750-0006 24751-0006 24752-0006
• Lateral Extension Adapter** *** 24700-0029 24700-0029 24700-0029
• Not illustrated.
* Included in Air Release/Fill Cap Package, Part No. 24750-0027.
** Available for lateral repairs.
*** Quantity as required.
† When ordering Lower Shell, also order Key Nos. 16 (tape) and 23 (Inlet-Outlet Label).
REPAIR PARTS LIST
