STA-RITE JWPA5C - Page 7

7
TABLE I - RECOMMENDED FUSING AND WIRING DATA
Model Motor Branch Fuse Max Load Voltage/ Dist. in Ft. (m) (Serv. to Motor) Temp.
Number H.P. Rating Amps* Amps Hz/Phase 0-100’ (0-30) 101-200’ (31-60) 201-300’ (61-90) Rating-°C
1-Speed
JWPA5C-2A8 1/2 15 9.0 115/60/1 14 (2) 12 (3) 10 (5.5) 75
JWPA5DL-2A 3/4 15 9.0 115/60/1 14 (2) 12 (3) 10 (5.5) 75
JWPA5DL-2A1 3/4 15 9.0 115/60/1 14 (2) 12 (3) 10 (5.5) 75
JWPA5DL-2A2 3/4 15 9.0 115/60/1 14 (2) 12 (3) 10 (5.5) 75
JWPA5D-2A 3/4 15 9.0 115/60/1 14 (2) 12 (3) 10 (5.5) 75
JWPA5D-2A4 3/4 15 9.0 115/60/1 14 (2) 12 (3) 10 (5.5) 75
JWPA5D-2A8 3/4 15 9.0 115/60/1 14 (2) 12 (3) 10 (5.5) 75
JWPA5D7L-2A 3/4 15 9.0 115/60/1 14 (2) 12 (3) 10 (5.5) 75
JWPA5D7L-2A1 3/4 15 9.0 115/60/1 14 (2) 12 (3) 10 (5.5) 75
JWPA5D7L-2A2 3/4 15 9.0 115/60/1 14 (2) 12 (3) 10 (5.5) 75
JWPA5EL-2A 1 15 12.0 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5EL-2A1 1 15 12.0 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5EL-2A2 1 15 12.0 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5E7-2A4 1 15 12.0 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5E7L-2A 1 15 12.0 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5E7L-2A1 1 15 12.0 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5E7L-2A2 1 15 12.0 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5F-2A 1
1
⁄2 20 16 115/60/1 10 (5.5) 8 (8.4) 6 (14) 75
JWPA5FL-2A 1
1
⁄2 20 16 115/60/1 10 (5.5) 8 (8.4) 6 (14) 75
JWPA5FL-2A1 1
1
⁄2 20 16 115/60/1 10 (5.5) 8 (8.4) 6 (14) 75
JWPA5FL-2A2 1
1
⁄2 20 16 115/60/1 10 (5.5) 8 (8.4) 6 (14) 75
JWPA5FL-A 1
1
⁄2 25/15 16.4/8.2 115/230/60/1 10/14 (5.5/2) 8/14 (8.4/2) 6/12 (14/3) 75
JWPA5F7L-2A4 1
1
⁄2 20 16 115/60/1 10 (5.5) 8 (8.4) 6 (14) 75
JWPA5D-230A 3/4 15 4.8 230/60/1 14 (2) 14 (2) 14 (2) 75
JWPA5E-230A 1 15 6.1 230/60/1 14 (2) 14 (2) 14 (2) 75
JWPA5E-230A2 1 15 6.1 230/60/1 14 (2) 14 (2) 14 (2) 75
2-Speed
JWPXYD-A2 3/4 – 1/8 15 11.7/3.39 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPXYDL-A2 3/4 – 1/8 15 11.7/3.39 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPAXYE-A2 1 – 1/8 15 11.7/3.39 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5YEL-A1 1 – 1/8 15 11.7/3.39 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5YEL-A2 1 – 1/8 15 11.7/3.39 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5YE7L-A1 1 – 1/8 15 11.7/3.39 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5YE7L-A2 1 – 1/8 15 11.7/3.39 115/60/1 14 (2) 10 (5.5) 8 (8.4) 75
JWPA5YFL-A 1
1
⁄2 – 1/6 20 16.0/3.6 115/60/1 12 (3) 8 (8.4) 6 (14) 75
JWPA5YFL-A2 1
1
⁄2 – 1/6 20 16.0/3.6 115/60/1 12 (3) 8 (8.4) 6 (14) 75
JWPA5YF7L-A1 1
1
⁄2 – 1/6 20 16.0/3.6 115/60/1 12 (3) 8 (8.4) 6 (14) 75
JWPA5YF7L-A2 1
1
⁄2 – 1/6 20 16.0/3.6 115/60/1 12 (3) 8 (8.4) 6 (14) 75
*Time delay fuses are recommended instead of standard fuses in any motor circuit.
Wire
Size
AWG
(mm)
}
Values given in table below are for PUMP MOTOR ONLY. If additional accessories are
installed on pump motor circuit (heater, blower, etc.), include their amperage draw
when figuring wire and circuit breaker sizes.
