STA-RITE Max-E-Therm® - Replacement Parts

Rev. B 6-23-08 P/N S794
49
MAX-E-THERM
®
REPLACEMENT PARTS
Repair Parts are available from your Pentair dealer.
If your dealer cannot supply you, call Customer Support at 1-800-831-7133.
4
1
3
4
5
6
8
10
9
2
7
12
1
For complete
Electrical System
parts breakdown
(Key Nos. 1 through 4),
See Page 53
For complete
Burner System
parts breakdown
(Key Nos. 5 through 9),
See Pages 51 and 52
For complete
Water System
parts breakdown
(Key Nos. 10 through 12),
See Page 52
