DURA
*
GLAS
TM
CENTRIFUGAL PUMPS
WITH INTEGRAL TRAP
O W N E R’ S M A N U A L
INSTALLATION, OPERATION & PARTS
P2R AND P2RA Series MODELS
H.P. P2R Series P2RA Series
1/2 P2R5C-120L P2RA5C-119L
3/4 P2R5D-124L P2RA5D-120L
1 P2R5E-125L P2RA5E-124L P2RAXE-124L
1-1/2 P2R5F-126L P2RA5F-125L P2RA6F-125L
1-1/2 – – P2RAXF-125ULS P2RAXF-125LS
2 – P2RA5G-126L P2RA6G-126L P2RAXG-126LS
Sta-Rite Pool/Spa Group
293 Wright Street, Delavan, WI 53115
North America: 800-752-0183, FAX 800-582-2217
International: 414-728-5551, FAX: 414-728-4461, TELEX: ITT 4970245
Oxnard, CA • Union City, TN • Delavan, WI • Mississauga, Ont.
Printed in U.S.A. © 1997, Sta-Rite Industries, Inc. S53 (Rev. 11/5/97)
This manual should be furnished to
the end user of this pump; its use
will reduce service calls and chance
of injury and will lengthen pump life.
