10
0049 / 63 46 / 3 09-0
GB
We have endeavoured to explain the unit's handling and functioning in as clear
and comprehensible manner as possible. If, however, you still have any unanswered
questions, we should be pleased to provide advice over the telephone at any time
on the following telephone number:
Operating instructions
The STABILA LAPR-150 rotation laser is an easy to operate rotation laser for horizon-
tal and vertical levelling and plumb lines. It is self-levelling in a range of ± 1°. The
laser beam can be received at distances of up to 90 m (570 ft) with the use of a
receiver, even when it is no longer visible to the naked eye.
O
(3b)
(4a)
(4b)
Main components
SP1: vertical beam emission aperture
SP2: rotation beam emission aperture
ON switch
Selector switch: Rotation function
Selector switch: Scan function
LEDs for displaying:
LED red : battery voltage and overheat
Shock protection
5/8" threaded connector for tripod
LED green : Operating mode ON or READY / OK
Rough alignment clamp
Battery compartment cover
OFF switch (for protecting during transport)
Rough adjustement vial
Splitter pentaprism SP:
(1)
(3a)
(2)
(5a)
(5b)
(5c)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
A
Motor housing
Deflection optics
Protection and carrying frame
O
