STACYC 16EDRIVE - LED Indicator Guide

P a g e | 10P a g e |
LED INFORMATION
POWER
SWITCH
THROTTLE
POSITION
SITUATION/ REACTION
LED
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ZERO
ZERO
ZERO
ZERO
5-10%
5-10%
5-10%
10%-FULL
10%-FULL
10%-FULL
NONE
RED
YELLOW
GREEN
G,Y,R
Y, R
R
G,Y,R
Y, R
R
cycle could be in program mode (exercise cauon with
the throle)
cycle powered on and in “TRAINING/LOW”
power mode
cycle powered on and in “NORMAL/MED”
power mode
cycle powered on and in “ADVANCED/FAST”
power mode
cycle powered on and showing FULL
baery charge
cycle powered on and showing MEDIUM
baery charge
cycle powered on and showing LOW
baery charge
Motor will engage & drive bike at selected power mode,
FULL baery charge
Motor will engage & drive bike at selected power mode,
MED baery charge
Motor will engage & drive bike at selected power mode,
LOW baery charge
