ST215C User Handbook Page
11
To enter the fan temperature configuration menu press the key and the key down
together while the controller is not running a program (firing indicator not lit).
Note: in the sequence below if no key presses are detected within 30 seconds the
ST215C will exit the menu and fan temperature changes will not be saved.
The fan start temperature prompt is shown.
Release the & keys.
Press the key.
The fan start temperature is now shown.
Adjust with the & keys (hold down for
acceleration).
Press the key.
The fan stop temperature prompt is now
shown.
Press the key.
The fan stop temperature is now shown.
Adjust with the & keys (hold down for
acceleration)
Press the key.
The ST215C will now reset and the new fan control temperatures will be stored.
Note: in the sequence above it is important that the key is pressed a total of 4
times else changes will not be saved.
Fan Output
Fan Operation
Prior to firing the fan will be off. During firing the fan will start when the kiln tempera-
ture has risen to the fan start temperature.
The fan will remain on until the kiln temperature has risen to the fan stop temperature.
The fan then turns off and remains off.
The event indicator is turned on while the fan is running.
Note: the event switch has no function for fan operation
