Page ST215C User Handbook
30
Setup Parameters
No. Function Min. Max. Default Notes
0 Thermocouple type 0 3 2 0=K, 1=N, 2=R, 3=S
1 Error 1 enable 0 1 1 0=disabled, 1=enabled
2 Max. user temperature 100 1400 1320 °C
3 Display brightness 0 6 3 0=dim, 6=bright
4 Error 4 enable 0 1 1 0=disabled, 1=enabled
5 Error 5 enable 0 1 0 0=disabled, 1=enabled
6 Error 6 firing hours trip 10 1000 1000 1000=disabled
7 Room temperature trip 30 71 50 °C. 71=disabled
8 Power fail recovery enable 0 1 1 0=disabled,1=enabled
9 Paused time limit (hours) 1 11 2 11=disabled
10 Set point offset -99 99 0 °C
11 Proportional band 1 999 55 °C
12 Integral time (seconds) 0 9999 200 0=disabled
13 Differential time (seconds) 0 999 10 0=disabled
14 Kiln element power 0 9999 0 1 unit = 0.1kW
43 Engineer lockup on error 0 1 0 0=disabled, 1=enabled
44 Control cycle time 5 120 30 Seconds
45 Event/Damper/Fan (RL3) Function 0 3 0 0=off, 1=event, 2=damper, 3=fan
46 Remember start delay 0 1 0 0=forget, 1=remember
47 Skip start delay after power failure 0 1 0 0=resume delay, 1=skip delay
50 USB Data Logging Sample Period 5 300 60 seconds
55 Disable setup password protection 0 1 1 0=enabled, 1=disabled
60 Operating units °C/°F 0 1 0 0=°C, 1=°F
Note: The setup parameters shown thus are freely adjustable. The other setup
parameters might be password protected - contact supplier.
