USER MANUAL PA4/200 & PA4/200 DSP
PA4/200 or PA4/200 DSP POWERED MIXER
Max. Output Power 2 x 75 W RMS / 4 Ohms
Bande passante 20 Hz à 20 kHz ± 1 dB
Input Impedance
MIC 1k Ohms
LINE 47k Ohms
CD/ TAPE 4.7k Ohms
Sensitivity (@ max Rated Power)
MIC - 49.5 dB
LINE - 16.5 dB
CD/ TAPE - 1.5 dB
Input Channel EQ
BASS +/- 15 dB @ 50 Hz
TREBLE +/- 15 dB @ 10 kHz
Master EQ
BASS +/- 15 dB @ 50 Hz
MID +/- 12 dB @ 2 kHz
TREBLE +/- 15 dB @ 10 kHz
Power Requirement 115V/60Hz or 230V/50 Hz
Dimensions (H x W x D) 120 x 480 x 260 mm / 4.7 x 18.9 x 10.2 in
Weight 8.66 Kg / 19.09 lbs
TECHNICAL SPECIFICATIONS :
SPEAKER CABINETS
1x 10” / 150 W RMS / 4 Ohms Speaker
1x Piezo Horn Tweete
Total Power Capacity 150 W / 4 Ohms
Sensitivity (1W @ 1m) 91 dB SPL
Freqency Response 50 Hz to 20 kHz
Cross-over Frequency 4 kHz
Dimensions (H x L x P) 505 x 370 x 310 mm / 19.9 x 14.6 x 12.2 in
Weight 12.58 Kg / 27.73 lbs
Features and Specications are subject to change without notice.
