The Connectors..................Continued
Using the Foot Pedals
Using the MIDI IN/OUT Ports
9
Connect the DIN plug of the footboard
to the “PEDAL” DIN socket on the rear
panel
. You will experience the sustain
effect
.
MIDI stands for Musical Instrument
Digital Interface. MIDI is a world wide
standard that allows various electronic
musical instruments and other devices
to communicate with each other.
MIDI IN: Data transmitted from other MIDI instruments via MIDI are received at this connector.
MIDI OUT: Data produced by the Digital Piano are transmitted to other MIDI instruments via
MIDI from this connector.
