Digital Piano Set-up Guide................Continued
A. Put the foot pedal unit(6) in between the left and right legs components (3&4), use 4 pieces
of screws (2 on each side) to stable the legs onto the foot pedal unit.
(Make sure the direction of the placement is correct before screwing)
2. Follow the illustration below and finish off the set-up procedures.
B. Use 4 pieces of screws (2 on each side) to tighten the back panel skirt (5) onto the
assembly finished in Part A.
4
To Next Page
