ASSEMBLY INSTRUCTIONS
6
Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all
packing materials from your area and place them back into the box. Do not dispose of the packing materials
until assembly is completed. Read each step carefully before beginning. If you are missing a part please
call our toll-free number for assistance 1 (800) 375-7520 or e-mail us at:
parts@staminaproducts.com
STEP 1: Loosen the ADJUSTMENT KNOB(41) on the FRONT FRAME(1). Slide the REAR
FRAME(2) backward and secure with the ADJUSTMENT KNOB(41). Attach the REAR STABILIZER(3)
onto the REAR FRAME(2) with CARRIAGE BOLTS(M8 x 70mm)(49), ACORN NUTS(M8)(61),
and WASHERS(M8)(63).
NOTE: You can adjust the LEVELING CAPS(44) on the FRONT FRAME(1) to keep the Bike
stable.
STEP 2: Attach the SEAT FRAME(4) onto the REAR FRAME(2) with CARRIAGE BOLTS
(M8 x 40mm)(48), NYLOCK NUTS(M8)(60), and WASHERS(M8)(63).
