ASSEMBLY INSTRUCTIONS
STEP 5
Attach the SWING ARM(8) to the MAIN FRAME(14) with BUTTON HEAD BOLT(M10x1.5x125mm)(30),
WASHERS(M10)(34), and NYLOCK NUT(M10x1.5)(31).
STEP 6
Insert the HANDLEBAR(5) into the SWING ARM(8) and secure with BUTTON HEAD BOLTS
(M8x1.25x15mm)(27), and ARC WASHERS(M8)(35).
