13
STORAGE
FOLDING THE INVERSION TABLE
The can be easily folded for storage.
To fold the
loosen LOCKING KNOB(17) and pull out the LARGE SPRING PIN(16).
Now, slide the HEIGHT ADJUSTMENT BEAM(6) all the way up into the MAIN FRAME(4) until the
ADJUSTABLE INSTEP FRAME(7) is just below the MAIN FRAME(4), release the LARGE SPRING
PIN(16) and slide the HEIGHT ADJUSTMENT BEAM(6) slightly up or down until the spring pin locks
the beam in place. Remove the
MAIN FRAME ASSEMBLY from the BASE by lifting up on the MAIN
FRAME(4) until the PIVOT ARMS(5) come out of the slots located at the top of the REAR FRAME(2),
(Make sure the NYLON STRAP is not attached to the MAIN FRAME(4) before attempting to remove it.)
Push up on the center of the
FOLDING LINKAGES(3) and push the FRONT FRAME(1) and REAR
FRAME(2) together until they meet.
MAINTENANCE INSTRUCTIONS
The safety level of the can be maintained only if it is examined regularly for damage and
wear.
Check the nylon strap, strap buckle, pivot arms, nylon bed, heel holders, small spring pin and large
spring pin for damage and wear.
Replace damaged and worn components immediately and/or keep the equipment out of use until repair.
1.
2.
