ASSEMBLY INSTRUCTIONS
STEP 4
NOTE: There are two sets of holes in the MAIN SUPPORT(3) which allows you to attach the FOAM ROLL
POST(8) to two different positions. Try the upper position rst.
Attach the FOAM ROLL POST(8) to the MAIN SUPPORT(3) with the SUPPORT PLATE(11), HEX
BOLTS (M10x1.5x70mm)(18), WASHERS(M10)(23), and NYLOCK NUTS(M10x1.5)(25). Press the NUT
CAPS(M10)(26) onto the bolt heads of HEX BOLTS(M10x1.5x70mm)(18) and NYLOCK NUTS(M10x1.5)
(25).
STEP 5
NOTE: There are two adjustment holes in the FOAM ROLL POST(8). These adjustment holes allow
users to adjust the position of the FOAM ROLLS(16). Try the upper hole rst.
Slide a FOAM ROLL(16) onto the SUPPORT TUBE(9). Insert the other end of the SUPPORT TUBE(9)
through the upper hole in the FOAM ROLL POST(8). Slide another FOAM ROLL(16) over the protruding
end of the SUPPORT TUBE(9).
8
