2. Operation Procedure

Stopper Handle

Accordion Fold

2-4 When Folding Is Not Even or Square

2-4-1 To correct uneven fold

Adjustment for Stopper 2

Adjustment for Stopper 1

In case that one side of folded sheet is too

long or short, adjust stopper position with

stopper handle.

NOTE

- Following chart shows style of delivered

sheet.

- Turn stopper handle gradually. Perform

test feed after each adjustment in order to

check result of adjustment.

is long

For L

is short

For S

is long

For L

is short

For S

is long

For L

is short For S

is long For L

is short For S

is long For L

is short For S

is long

For S

is short For L

is long For S

is short For L

is long

For S

is short For L

is long For S

is short For L

is long

For S

is short For L

is long

For S

is short

For L

Appearance of

Delivered

Sheet

Appearance of

Delivered

Sheet

Gate Fold

Letter Fold

Short Fold

Parallel Fold

Single Fold

Gate Fold

Accordion Fold

Letter Fold

Short Fold

Parallel Fold

Single Fold
