4. Maintenance
27
Feed Roller
4-1 Feed Roller/Double Feed Stop Pad Replacement
5. Pull double feed stop pad upward to
remove.
6. Clean feed roller and double feed stop
pad with our original rubber cleaner
liquid, XPF-111.
- If feed roller or double feed stop pad is
worn out, replace it.
- Attach double feed stop pad and feed
roller in reverse order of detachment.
Double Feed
Stop Pad
