Stanley 70500 - Parts List

6.2 PARTS LIST
70500-02000 Parts List
ITEM PART NUMBER DESCRIPTION QT Y.
1 07001-00114 10-24UNC BUTTON HEAD SCREW 2
2 07001-00243 GRUB SCREW 1
3 07001-00250 M8 SOCKET HEAD CAP SCREW 1
4 07003-00248 O-RING SEAL 1
5 07003-00028 O-RING SEAL 1
6 07003-00033 BONDED SEAL 2
7 07003-00264 O-RING SEAL 2
8 07003-00042 O-RING SEAL 5
9 07003-00067 O-RING SEAL 2
10 07003-00100 O-RING SEAL 3
11 07003-00147 O-RING SEAL 1
12 07003-00153 O-RING SEA 4
13 07003-00178 O-RING SEAL 1
14 07003-00242 HYDRAULIC SEAL 1
15 07003-00243 HYDRAULIC SEAL 1
16 07004-00057 CIRCLIP 3
17 07007-00017 DUST CAP 1
18 07007-00353 PROTECTIVE PLUG 1
19 07151-00403 TURRET JAW 2
20 07271-01100 CURSOR ASSEMBLY 1
21 07650-00218 SPRING GUIDE 2
22 07650-00303 TURRET 1
23 07650-00501 BARREL LOCK NUT 2
24 07657-00302 ADAPTOR 1
25 07003-00036 O-RING SEAL 1
26 07657-00305 PISTON 3
27 07657-00306 PISTON ROD 2
28 07657-00307 REAR CYLINDER 2
29 07657-00308 REAR PLUG 1
30 07657-00309 SEAL RETAINER 3
31 07660-00202 BARREL WASHER 2
32 07667-00207 BARREL NUT 1
33 70500-02001 BARREL 1
34 70500-02002 SEAL SPRING GUIDE 1
35 70500-02003 BARREL SPRING RETAINER 1
36 70500-02004 BARREL SPRING 1
37 70500-02005 SPACER 1
38 70500-02006 BODY 1
39 70500-02007 PISTON GUIDANCE TAPE-LONG 1
40 70500-02008 PISTON GUIDANCE TAPE-SHORT 1
41 70500-02009 PISTON 1
42 70500-02010 TAIL JAW HOUSING 1
43 70500-02011 BANJO 1
44 70500-02012 FRONT CYLINDER 1
45 70500-02013 JAW HOUSING 1
46 70500-02014 LOCKNUT 1
47 70500-02015 PISTON NUT 1
48 70500-02016 BUFFER STOP 3
49 70500-02017 FRONT PISTON ROD 1
50 07273-00203 SAFETY LABEL (NOT SHOWN) 1
51 73200-02022 SAFETY LABEL (NOT SHOWN) 1
52 07007-02223 ADDRESS LABEL (NOT SHOWN) 2
53 07001-00481 GRUB SCREW M5 CUP 1
12
ENGLISH ORIGINAL INSTRUCTION
