by a 16 A fuse. Before you use the machine,
make sure that the mains voltage complies with
thespecificationsontheratingplate.Longsupply
cables,extensions,cablereelsetc.causeadropin
voltageandcanimpedemotorstart-up.Inthecase
oflowtemperaturesbelow+5°C,motorstart-upis
jeopardizedasaresultofstiffness.
5.4 On/Off switch (ref. 8)
5.4.1 D 200/8/24 - D 200/10/24 (Fig. 2a)
Toswitch on the equipment set the On/Offswitch
(ref.8)topositionI.
Move the On/Off switch (ref. 8) to position O to
switchofftheequipment.
5.4.2 D 200/8/6 (Fig. 2b)
Toswitchonthecompressor,pullouttheredknob
(ref.8)to position I.
To switch off the compressor, press the red knob
(ref.8)inagainto position O.
5.5 Adjusting the pressure
● You can adjust the pressure on the pressure
gauge(ref.6)usingthepressureregulator(ref.
7).
● Thesetpressurecanbetakenfromthequicklock
coupling(ref.5).
5.6 Setting the pressure switch
Thepressureswitchissetatthefactory.
5.6.1 D 200/8/6 - D 200/8/24
Switch-onpressure6bar
Switch-offpressure8bar
5.6.2 D 200/10/24
Switch-onpressure8bar
Switch-offpressure10bar
6. CLEANING AND MAINTENANCE
Warning!
Pull the power plug before doing any cleaning
and maintenance work on the appliance.
Warning!
Wait until the compressor has completely cooled
down. Risk of burns!
Warning!
Always depressurize the tank before carrying
out any cleaning and maintenance work.
6.1 Cleaning
● Keep the safety devices free of dirt and dust
as far as possible. Wipe the equipment with a
clean cloth or blow it with compressed air at low
pressure.
● We recommend that you clean the appliance
immediatelyafteryouuseit.
● Cleantheapplianceregularlywithadampcloth
andsomesoftsoap.Donotusecleaningagents
or solvents; these may be aggressive to the
plastic parts in the appliance. Ensure that no
watercangetintotheinterioroftheappliance.
● Youmustdisconnectthehoseandanyspraying
toolsfromthecompressorbefore cleaning. Do
not clean the compressor with water, solvents or
thelike.
6.2 Condensation water
Thecondensationwatermustbedrainedoffeach
daybyopeningthedrainvalve(ref.11)(onthefloor
ofthepressurevessel).
Warning!
The condensation water from the pressure
vessel will contain residual oil. Dispose of the
condensation water in an environmentally
MAINTENANCE RESUMPTIVE TABLE
FUNCTION
AFTER THE FIRST
100 HOURS
EVERY 100 HOURS
Cleaning of intake filter and/or
substitution of filtering element
● ●
Draining tank condensate Periodically and at the end of work
