the terminal box of the motor must be pressed
(fig. 13).
● Onthree-phaseversions,simplyreturnthebutton
ofthepressureswitchtotheONposition.(fig.
12).
● Single-phaseversionsarefittedwithapressure
switch equipped with a delayed closing air
discharge valve which facilitates start-up of the
motor.Thereforeventingofairfromthisvalvefor
afewsecondswiththereceiveremptyisnormal.
● All the compressors are fitted with a safety valve
that is tripped in the case of malfunctioning of
the pressure switch in order to assure machine
safety.
● When fitting a tool, the flow of air in output must
beswitchedoff.
● When using compressed air, you must know and
comply with the safety precautions to be adopted
foreachtypeofapplication(inflation,pneumatic
tools, painting, washing with water-based
detergentsonly,etc.).
2. LAYOUT
1. Intakeairlter
2. Pressurevessel
3. Wheel
4. Supportingfoot
5. Quick-lockcoupling(regulatedcompressedair)
6. Pressuregauge(forreadingthepresettank
pressure)
7. Pressureregulator
8. ON/OFFswitch
9. Transportationhandle
10.Safetyvalve
11. Receivercondensationdrainagetap
12.Pressuregauge(forreadingthetankpressure)
13.Quick-lockcoupling(unregulatedcompressed
air)
14.Oildipstick(oillleropening)
15.Oildrainagescrew
16.Axle
17.Clip
18.Bolt
19.Nut
20.Washer
3. SCOPE OF USE
The compressor is designed for generating com-
pressedairfortoolsoperatedbycompressedair.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications.Ourwarrantywillbevoidedifthema-
chine is used in commercial, trade or industrial busi-
nessesorforequivalentpurposes.
Themachine is tobe usedonly forits prescribed
purpose.Anyotheruseisdeemedtobeacaseof
misuse.Theuser/operatorandnotthemanufac-
turer will be liable for any damage or injuries of any
kindcausedasaresultofthis.
4. POINTS TO NOTE WHEN SET-
TING UP THE COMPRESSOR
● Examine the machine for signs of transit dam-
age.Reportanydamageimmediatelytothe
companywhichdeliveredthecompressor.
● Thecompressorshouldbesetupnearthework-
ingconsumer.
● Avoidlongairlinesandlongsupplylines(exten-
sions).
● Makesuretheintakeairisdryanddust-free.
● Do not set up the compressor in damp or wet
rooms.
● Thecompressormayonlybeusedinsuitable
rooms(withgoodventilationandanambient
temperaturefrom+5°Cto+40°C).Theremust
be no dust, acids, vapors, explosive gases or
inammablegasesintheroom.
● Thecompressorisdesignedtobeusedindry
rooms.Itisprohibitedtousethecompressor
in areas where work is conducted with sprayed
water.
● Theoillevelinthecompressorpumphasto
be checked before putting the equipment into
operation.
