Page #19 background image
MC521 PRO Control Box
03.23.2017
1.800.7.ACCESS • www.stanleyaccess.com • Document # 204090 REV D 17
Copyright 2017 Stanley Access Technologies, LLC. All rights reserved. Reproduction
in whole or in part without the express written permission of Stanley is prohibited.
Table 4. Magic Force/Magic Swing Configuration Codes -- Motor 1 Continued
Index
Min.
Value
Max.
Value
Description
Defaults
Low
Energy
Full
Energy
11 00 04 Safety Logic. INDEX 11 - 00 to 15
00 = Sensor
01 = Sentrex
02 = Carpet
03 = Carpet 12 Sec.
04 = Non-Monitored Bi-Fold
05 = Monitored DM & OHP. ACT, STL & SAF, both
single & pair
06 = Monitored DM & OHP Dual Egress. STL, ACT,
STL & SAF
07 = Monitored OHP & Photobeam. SAF &
Photobeam
08 = Monitored DM ACT. ACT both single & pair
09 = Monitored OHP Bi-Fold. SAF
10 = Monitored DM. ACT & STL both single & pair
11 = Two OHP Monitored Bi-fold. SAF, Bi-Fold/Swing
12 = Monitored Hub Based Sensors. ACT & STL
13 = Swing-Guard T
14 = Monitored DM Stall & OHP both single and pair.
STL & SAF
15 = Monitored DM Stall & OHP Dual Egress. STL & SAF
00 00
12 00 01 2S Operaon, 00 = OFF, 01 = ON 00 00
13 01 60 Obstrucon Time (percent) (60 = 1.5 seconds) 20 20
14 20 60 Open Acceleraon Slope 60 60
15 20 40 Open Braking Slope 35 35
16 00 50 Operate Delay. Motor 1 (0.1 sec. increments: 5.0 sec. max.) 00 00
17 00 01 No Reverse on Obstrucon (00 O, 01 On) NA NA
18 00 50 Lock Delay (0.1 sec. increments, 5.0 sec. max.) 00 00
19 00 01 Manual Mode sensor override (00 O, 01 On) 00 00
ABBREVIATIONS:
DM - Door Mounted Sensors
OHP - Overhead Presence Sensor
ACT - Acvaon Side Presence Sensor
STL - Stall Presence Sensor
SAF - Safety Presence Sensor
