10
ENGLISH
(Original instructions)
Your charger does not require any maintenance apart from
regular cleaning.
Warning! Before performing any maintenance on the tool,
remove the battery from the tool. Unplug the charger before
cleaning it.
u Regularly clean the ventilation slots in your tool and
charger using a soft brush or dry cloth.
u Regularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
u Regularly open the chuck and tap it to remove any dust
from the interior.
Protecting the environment
Z
Separate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries accord-
ing to local provisions. Further information is available at
www.2helpU.com.
Technical data
KFMCD628 H2
Voltage V
DC
18V
No-load speed Min
-1
0-430/0-1700
Max. torque Nm
55
Chuck capacity mm
13
Max Drilling capacity
Steel/wood mm 13/35
Weight kg
1.5
Charger
905998** 906086 906364**
Input voltage V
AC
230 230 230
Output voltage V
DC
18 18 20
Current mA
1000 2000 1000
Approx. charge time Mins
80-240 40-120 80-240
Battery
FMC685L FMC687L FMC684L
Voltage V
AC
18 18 18
Capacity Ah
1.5 2.0 1.3
Type
Li-Ion Li-Ion Li-Ion
Level of sound pressure according to EN 62841:
Sound pressure (L
pA
) 93.5 dB(A), uncertainty (K) 5 dB(A)
Sound power (L
WA
) 104.5 dB(A), uncertainty (K) 5 dB(A)
Vibration total values (triax vector sum) according to EN 62841:
Drilling into metal (a
h, D
) 1.4 m/s
2
, uncertainty (K) 1.5 m/s
2
Impact drilling into concrete (a
h.ID
) 11.3 m/s
2
, uncertainty (K) 1.5m/s
2
Declaration of conformity
The Supply of Machinery (Safety)
Regulations 2008
KFMCD628 - Impact Drill
Stanley Fat Max declares that these products described under
“technical data” are in compliance with:
The Supply of Machinery (Safety) Regulations, 2008, S.I.
2008/1597 (as amended).
EN62841-1:2015, EN62841-2-1:2018+A11:2019.
These products conform to the following UK Regulations:
Electromagnetic Compatibility Regulations, 2016,
S.I.2016/1091 (as amended).
The Restriction of the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment Regulations 2012, S.I.
2012/3032 (as amended).
For more information, please contact Stanley Fat Max at the
following address or refer to the back of the manual.
The undersigned is responsible for compilation of the
technical le and makes this declaration on behalf of
Stanley Fat Max.
Karl Evans
Vice President Professional Power T
ools
Stanley Fat Max UK, 270 Bath Road, Slough
Berkshire, SL1 4DX
United Kingdom
30/09/2021
