Stanley FMC625 User Manual

8
ENGLISH
(Original instructions)
Batteries
Z
Stanley FatMax batteries can be recharged many
times. At the end of their useful life, discard batteries
with due care for our environment:
u Run the battery down completely, then remove it from the
tool.
u NiCd, NiMH and Li-Ion batteries are recyclable. Take them
to any authorised repair agent or a local recycling station.
Technical data
FMC625 (H1)
Voltage V
DC
18
No-load speed Min
-1
0-400/0-1600
Max. torque Nm 51.4
Chuck capacity mm 13
Max Drilling capacity
Steel/wood/
masonry
mm 13/38/13
Charger
905998**
typ. 1
906086**
typ. 1
Input Voltage V
AC
230 230
Output Voltage V
DC
18 18
Current A 1 2
Approx. charge time min
90 - 240 45 - 120
Battery
FMC685L FMC687L FMC688L
Voltage V
DC
18 18 18
Capacity Ah 1.5 2.0 4.0
Type Li-Ion Li-Ion Li-Ion
Level of sound pressure according to EN 60745:
Sound pressure (L
pA
) 88.1 dB(A), uncertainty (K) 3 dB(A)
Sound power (L
WA
) 99.1 dB(A), uncertainty (K) 3 dB(A)
Vibration total values (triax vector sum) according to EN 60745:
Impact drilling into concrete (a
h, ID
) 13.1 m/s
2
, uncertainty (K) 1.5 m/s
2
Drilling into metal (a
h, D
) < 2.5 m/s
2
, uncertainty (K) 1.5 m/s
2
Screwdriving without impact (a
h, s
) < 2.5 m/s
2
, uncertainty (K) 1.5 m/s
2
Australia & New Zealand
Stanley Black & Decker
82 Taryn Drive, Epping, VIC 3076 Australia
Tel.1800 338 002 (Aust) or Tel. 0800 339 258 (NZ)
90611688
05/14

Stanley FMC625 Specifications

General

Torque (max)	51.4 N⋅m
Number of gears	2
Torque settings	22
Chuck capacity (min)	1.5 mm
Idle speed (1st gear)	400 RPM
Idle speed (2nd gear)	1600 RPM
Impact rate (low speed)	6800 bpm
Impact rate (high speed)	27200 bpm
Drilling diameter in wood (max)	38 mm
Drilling diameter in concrete (max)	13 mm
Soft grip	Yes
Product color	Black, Yellow
Product design	Pistol grip drill
Power source	Battery
Charging time	60 min
Battery voltage	18 V
Battery capacity	2 Ah
Number of batteries included	2 pc(s)

Weight and Dimensions

Depth	55 mm
Width	230 mm
Height	220 mm
Weight	1800 g
