Stanley PD45 User Manual

16 ► PD45 User Manual
ITEM
PART
NO. QTY DESCRIPTION
1 15190 1 TOP PLATE
2 11588 1 ACCUMULATOR VALVE BLOCK
3 04374 4 LOCK NUT 5/8-18
4 00293 1 O-RING
5 15188 1 VALVE SPOOL
6 07493 1 MALE O-RING PLUG
7 20499 1 CHARGE VALVE
8 07479 1 ACCUMULATOR DIAPHRAGM
9 04381 2 BACK-UP RING
10 04379 2 O-RING
11 04378 1 PORTING BLOCK
12 04571 2 PUSH PIN
13 04382 1 AUTOMATIC VALVE
14 04605 4 PUSH PIN
15 04383 1 FLOW SLEEVE TUBE
16 12139 4 SIDE ROD
17 02022 1 O-RING
18 04386 1 CUP SEAL
19 04780 1 WASHER
20 04387 1 ROD WIPER
21 370351 4 CAPSCREW
22 72592 1 ADAPTER BLOCK (IF ORDERING
ADAPTER BLOCK YOU MUST ORDER
P/N 72592 ADAPTER BLOCK ASSY
WHICH INCLUDES ITEMS 32 & 33)
23 15189 1 ANVIL
24 15170 1 POST DRIVER FOOT
25 15182 2 HANDLE BAR
26 15194 2 SET SCREW, 3/8-16 × 1/2 HSH
27 04058 1 SPRING
28 07480 1 AUTOMATIC VALVE BODY
29 07481 1 PISTON
30 07485 1 FLOW SLEEVE
31 12146 1 SPRING
32 72592 1 UPPER ANVIL STOP (IF ORDERING
UPPER ANVIL STOP YOU MUST
ORDER P/N 72592 ADAPTER BLOCK
ASSY WHICH INCLUDES ITEMS 22 &
33)
33 72592 1 ANVIL BUSHING (IF ORDERING ANVIL
BUSHING YOU MUST ORDER P/N
72592 ADAPTER BLOCK ASSY WHICH
INCLUDES ITEMS 22 & 32)
34 00856 2 1/2 INCH SAE TO 1/2 INCH TUBE
35 66722 2 HOSE ASSY (PD45131 & PD4513103)
35784 2 HOSE ASSY (PD45131J)
36 — — NO ITEM
37 00026 1 O-RING
ITEM
PART
NO. QTY DESCRIPTION
38 02900 2 ROLL PIN
39 74808 1 PD45 NAME TAG
40 00936 2 ADAPTER
41 19693 1 DANGER STICKER
42 13568 2 BACK UP RING (OLD IN-LINE VALVE)
42A 07224 2 BACK UP RING (NEW IN-LINE VALVE)
43 13567 2 O-RING (OLD IN-LINE VALVE)
43A 07626 2 O-RING (NEW IN-LINE VALVE)
44 01003 2 ON-OFF VALVE BUTTON (OLD IN-LINE
VALVE)
44A 56749 2 SEAL CAP (NEW IN-LINE VALVE)
45 10536 1 SELECTOR SCREW
46 03972 1 FEMALE COUPLER 3/8 NPT
47 03973 1 MALE COUPLER 3/8 NPT
48 16070 1 RETAINING RING
49 38631 1 VALVE SPOOL (OLD IN-LINE VALVE)
49A 67008 1 VALVE SPOOL (NEW IN-LINE VALVE)
50 38629 1 VALVE BODY ASSY (OLD IN-LINE
VALVE)
50A 67007 1 VALVE BODY ASSY (NEW IN-LINE
VALVE)
51 11499 2 ADAPTOR 1/2 INCH SAE–3/8 NPTF
52 56747 2 SEAL WIPER
53 01604 2 O-RING
54 72264 1 IN-LINE VALVE ASSY
04595 SEAL KIT
Read Before Ordering In-line Valve Parts:
In-line Valve Assembly (OC-CC) - 72264
Includes Items (37, 42 through 45, thru 50, 52, and
53)
The in-line valve changed around June 2011. To
determine if you have the old or new in-line valve,
see parts illustration.
Note: Individual parts are still available for the older
in-line valve but if replacing the entire in-line valve
assy, you must order the new in-line valve assy P/N-
72264.
For Post Adaptors (See Page 18).
PD45131 PARTS LIST
