14 ► RD12 User Manual
RAIL SIZE
RD12 DRILL TEMPLATE SETS:
DOUBLE SIDED/
(SINGLE SIDED) GUIDE ASSY P/N: ING (MM)/[INCHES] COUNTRY
50 KG N 31975 (43583) 29963 (77 × 130 ×130) CHINA
60 KG (69512) 69510 (76 × 140 × 140) CHINA
46 KG U 33 31973 FRANCE
50 KG U 50 31974 29434 (60 × 170) FRANCE
LP48 31973 FRANCE
60 KG UIC 31974 29434 (60 × 170) FRANCE
S49 31976 / (31982) 31772 (46 × 165) GERMANY
S54 31976 / (31982) 31772 (46 × 165) GERMANY
60 KG UIC/UNI 31976 / (31983) 31772 (46 × 165) GERMANY
54 KG UIC ^34261 HOLLAND
NP46 ^34261 HOLLAND
I.R.S. 52KG (66830) 66831 (80 × 166) INDIA
60KG UIC (31983) 66831 (80 × 166) INDIA
36 KG U 33 ITALY
50 KG UNI ** 31976 / (31982) 30675 (47 × 165) ITALY
60 KG UIC/UNI 31976 / (31983) 30675 (47 × 165) ITALY
60 KG 31975 29963 (77 × 130 × 130) JAPAN
50 KG N 31975 (43583) 29963 (77 × 130 × 130) JAPAN
P50 (66321 HD) 66324 (65 × 150 × 140) RUSSIA
P65 (66323 HD) 66326 (95 × 220) RUSSIA
54KG UIC ^34261 ^32276 (58 × 170) SPAIN
37 KG JIS/JRS ^(43580) 44927 (60.5 × 127) TAIWAN
50 KG N 31975 ^(43583) 29963 (77 × 130 × 130) TAIWAN
60 KG UIC 31976 31772 (46 × 165) TAIWAN
87LB B.H. ^(35251) UK
90LB B.H. ^(35255) ^(35284) (60 × 114) UK
92LB F.B. ^(35257) ^(35283) (54 × 114) UK
95LB F.B. MARK A ^(35249) UK
95LB F.B. MARK B ^(35470) UK
98 UK
109BR UK
54KG UIC (BS 113A) 70MM HOLE
ELEVATION
34261 38889 (65 × 200) UK
UIC60 INSULATED (71558) 71459 (62 × 170 × 170) UK
CIE 50 ^(39233) 39236 (57 × 120) UK
RILC/RILR *(E32009) EUROPE
RI60/RI60N *(E32010) EUROPE
PH37 *(E32011) EUROPE
* = NOT RELEASED, TEMPLATE ONLY NOT A SET
^ = AVAILABLE BY SPECIAL ORDER ONLY
# = REQUIRES CHAMFERED CYLINDER CASTING
TEMPLATES & HOLE GUIDES
