RD12 User Manual ◄ 19
ITEM
PART
NO. QTY DESCRIPTION
1 24871 4 CAPSCREW
2 24844 1 CARRY HANDLE
3 31097 1 OPERATION DECAL
4 ----- 1 NO ITEM
5 34059 1 PRESSURE RELIEF VALVE
6 25774 1 TAMPER RESISTANT COVER
7 24868 1 FLOW CONTROL
8 00955 4 1/8" PIPE PLUG
9 74765 1 RD12 MODEL NO. STICKER
10 15909 4 CAPSCREW
11 60787 1 FITTING
12 24441 1 FILTER WASHER
13 — — NO ITEM
14 60785 1 COVER
15 73680 1 RAILROAD HELP DESK STICKER
16 370251 2 CAPSCREW
17 03061 2 LOCK WASHER
18 02003 1 O-RING 2-113 R16 •
19 24878 1 FACE SEAL
20 60782 1 PLUG ASSY
21 24783 1 SPRAY CAN
21A 24774 1 SPRAY CAN ASSY (INCL 21, 94 & 95)
22 04054 1 O-RING 2-233 R17
23 76777 1 PISTON RING
24 31286 1 PISTON MACHINING ASSY
25 29303 1 WATER VALVE
26 29302 1 WAVE SPRING
27 29301 1 RETAINING RING
28 60783 1 CYLINDER MACHINING ASSY
29 31828 2 KNOB
30 371067 5 FLAT WASHER
31 01459 12 LOCK WASHER
32 30652 2 RETAINING RING
33 29126 2 DOWEL PIN
34 29125 2 DOWEL PIN
35 07287 1 QUAD RING •
36 24881 1 WIPER SEAL •
37 17904 3 RETAINING RING
38 29197 1 CLEVIS PIN
39 28228 3 WASHER
40 28902 2 PLATE
41 29136 2 LINK
42 31069 1 SPACER
43 29075 1 STOP
44 28955 1 THREADED SHAFT
ITEM
PART
NO. QTY DESCRIPTION
45 20876 2 WASHER
46 01924 1 COTTER PIN
47 06173 9 CAPSCREW
48 17572 2 PINCH POINT WARNING STICKER
49 29072 1 HANDLE WELDMENT
50 38581 1 SETSCREW
51 02916 1 SPRING
52 35724 1 ADJUSTMENT SCREW
53 39449 1 ADJUSTMENT NUT
55 29070 1 CLAMP ARM LH
56 28867 1 GROMMET
57 29123 1 TORX SCREW DRIVER
58 24818 2 OIL TUBE
59 00055 4 O-RING 2-012 R17 •
60 29127 1 DOWEL PIN
61 08928 2 BACK-UP RING 9/16 × 3/32 •
62 29134 1 HYDRAULIC MOTOR
63 19095 2 O-RING 2-114 R17 •
64 00253 1 O-RING 2-038 R16 •
65 22521 1 QUICK DISCONNECT NIPPLE
66 27618 1 VALVE BLOCK ASSEMBLY
67 20145 2 STEEL BALL
68 01411 1 O-RING 3-906 R17 •
69 24289 1 PLUG
70 04119 1 PIPE PLUG
71 03972 1 FEMALE COUPLER BODY
72 24300 1 SETSCREW
73 24876 1 SPRING
74 20761 2 BEARING RACE
75 07890 1 ROLL PIN
76 34585 1 GROMMET
77 24305 12 SPRING WASHER
78 01362 4 O-RING 2-011 R16 •
79 24231 3 GROMMET
80 24877 1 ROTOR ASSY
81 24233 1 SHAFT
82 20762 1 BEARING
83 17924 1 O-RING 2-012 R24 •
84 02177 1 O-RING 2-137 R17 •
85 24313 1 HOUSING ASSY
86 26297 4 CAPSCREW
87 17527 1 VALVE CAP
88 24291 1 ROD
89 02633 1 KNOB
90 03973 1 MALE COUPLER BODY
RD12 PARTS LIST
