20 ► RD12 User Manual
ITEM
PART
NO. QTY DESCRIPTION
91 00936 2 ADAPTER
93 00698 2 HELICOIL
94 22748 1 HOSE CLAMP 9/16
95 24784 1 QUICK DISCONNECT COUPLER
96 29071 1 CLAMP ARM RH
97 — — NO ITEM
98 28322 1 CE STICKER
99 31049 1 EYE PROTECTION STICKER
100 28788 1 MANUAL STICKER
101 11207 1 CIRCUIT D STICKER
102 51296 1 SOUND POWER LEVEL STICKER 102
DBA
103 35725 1 PLUNGER
104 35726 1 ADJUSTMENT SCREW ASSY
(IF PURCHASED AS AN ASSEMBLY,
THIS CAN BE INSTALLED ON ALL
RAIL DRILLS.)
105 65622 1 NO LONGER AVAILABLE
106 31098 1 SCREEN
107 31099 1 GASKET
108 31100 1 END CAP
109 00961 1 PIPE PLUG
110 28956 1 ADJUSTMENT SCREW
111 24874 1 SETSCREW
112 24873 1 PLASTIC KNOB
113 67475 1 RD12 CLAMP ASSEMBLY (INCLUDES
ITEMS 30, 31, 37 THRU 55, 96, 102,
103, 111 & 112)
Seal Kit P/N 32031 (• Denotes part in Seal Kit)
Motor Seal Kit P/N 28658
RD12 PARTS LIST
RD12 Clamp Assembly P/N- 67475
Includes the following: Items 30, 31, and 37
thru 55, 96, 102, 103, 111 and 112.
113
111
112
