RS25 PARTS LIST
ITEM
PART
NO. QTY DESCRIPTION
6 28181 1 BELL CRANK
15 30958 1 “D” WASHER
20 66136 1 HANDLE WELDMENT
26 — 1
*
REFER TO ITEM 131
27 30671 1 ASSIST HANDLE
28 31030 1 HANDLE GRIP
29 31181 5 BELLEVILLE WASHER
30 30667 1 SHOULDER BOLT
31 31138 1 VALVE SPOOL
32 01604 2 O-RING
33 02931 1 VALVE CAP
34 00112 1 QUAD RING
35 31853 1 FLOW CONTROL (16 IN MODEL ONLY)
31854 1 FLOW CONTROL (14 IN MODEL ONLY)
36 08104 1 SAE PLUG
38 02920 1 SPACER
39 22707 1 TRIGGER
40 22704 1 SAFETY CATCH
41 22701 1 TORSION SPRING
42 03009 1 ROLL PIN
43 00165 1 SCREW
44 02911 1 HOSE CLIP
45 31186 1 POPPET
46 28552 1 VALVE HANDLE ASSY (INCL ITEM 36)
47 17641 1 WHEEL SAFETY LABEL (16 IN MODEL)
05868 WHEEL SAFETY LABEL (14 IN MODEL)
48 17681 1 ROLL PIN
49 24869 1 HANDLE
50 35289 1 MOTOR MOUNT ASSY
51 02688 4 CAPSCREW
52 30632 1 DOUBLE CAM
53 30635 1 SPIROL PIN
54 29510 1 EYE BOLT
55 04856 1 RETAINING RING
56 30841 2 WASHER
58 28673 1 SPRING
59 30412 1 MOTOR MOUNT PIVOT
60 30530 1 DISCONNECT PIVOT
61 28711 1 TOLERANCE RING
62 30543 1 STUD
63 04353 1 LOCKNUT
75 56708 1 CLAMP SCREW ASSY
77 03012 1 JAM NUT
78 62291 1 OUTER COLLAR
ITEM
PART
NO. QTY DESCRIPTION
79 62290 1 INSIDE COLLAR
80 00720 1 SET SCREW
81 23246 1 DOWEL PIN
82 59050 1 THRUST COLLAR
83 30219 1 RETAINING RING
84 31034 A/R SHIM, .005
85 31032 A/R SHIM, .020
86 31033 A/R SHIM, .010
87 30957 1 WHEEL GUARD (16 IN MODEL)
28709 1 WHEEL GUARD (14 IN MODEL)
73168 WHEEL GUARD (16 IN MODEL) LOW
SPARK (SEE PHOTO PAGE 19)
88 17652 1 SECTOR
89 28729 1 CARRIAGE BOLT
90 01594 2 WASHER
91 03906 1 LOCKNUT
92 17676 2 CAPSCREW
93 03006 2 MACHINE SCREW
94 66134 1 MOTOR ASSY (16 IN, CAN ONLY BE
PURCHASED AS AN ASSEMBLY)
66133 1 MOTOR ASSY (14 IN, CAN ONLY BE
PURCHASED AS AN ASSEMBLY)
103 00283 3 LOCK WASHER
104 16260 3 CAPSCREW
105 00772 1 KEY
110 00698 2 HELICOIL
111 03973 1 MALE COUPLER BODY (PARKER)
47437 1 MALE COUPLER BODY (AEROQUIP)
112 03972 1 FEMALE COUPLER BODY (PARKER)
47436 1 FEMALE COUPLER BODY
(AEROQUIP)
113 31137 1 PLUG
114 02916 1 SPRING
115 56725 2 HOSE ASSY (PARKER)
66727 1 HOSE ASSY (AEROQUIP)
116 00175 4 O-RING
117 29604 2 OIL TUBE
118 30922 1 O-RING (16 IN MODEL)
350771 1 O-RING (14 IN MODEL)
119 30921 1 QUAD RING (16 IN MODEL)
00214 1 QUAD RING (14 IN MODEL)
122 28728 1 NAME TAG (16 IN MODEL
28409 1 COMPOSITE STICKER (14 IN MODEL)
123 25610 1 RAILROAD HELP DESK (16 IN MODEL)
28728 1 NAME TAG (14 IN MODEL)
124 03787 1 GPM STICKER (16 IN MODEL)
