8
ENGLISH
• Move charger and battery pack to a location where
the surrounding air temperature is approximately 65°F
- 75°F (18°- 24°C). d. If charging problems persist, take
the tool, battery pack and charger to your local Stanley
Fat Max service center.
• The battery pack should be recharged when it fails to
produce sufcient power on jobs which were easily done
previously.
• DO NOT CONTINUE to use under these conditions.
Follow the charging procedure.
• You may also charge a partially used pack whenever you
desire with no adverse affect on the battery pack.
Installing and Removing the Battery Pack
from the tool
Warning!
Make certain the lock-off button is engaged to
prevent switch actuation before removing or installing battery.
To install battery pack
• Insert battery pack rmly into tool until an audible click is
heard as shown in gure A. Ensure battery pack is fully
seated and fully latched into position.
To remove battery pack
• Depress the battery release button (7) as shown in gure
B and pull battery pack out of tool.
Trigger switch & forward/reverse button -
gure C
• The drill is turned ON and OFF by pulling and releasing
the trigger switch (1) shown in gure C. The farther the
trigger is depressed, the higher the speed of the drill.
• A forward/reverse control button (2) determines the
rotational direction of the tool and also serves as a lock
off button.
• To select forward rotation, release the trigger switch and
depress the forward/reverse control button on the right
side of the tool.
• To select reverse, depress the forward/reverse control
button on the left side of the tool.
• The center position of the control button locks the tool
in the off position. When changing the position of the
control button, be sure the trigger is released.
Adjusting torque control - gure D
This tool is tted with a torque adjustment collar (3) to select
the operating mode and to set the torque for tightening
screws. Large screws and hard work piece materials require
a higher torque setting than small screws and soft work piece
materials.
• For drilling in wood, metal and plastics, set the collar to
the drilling position symbol.
• For screwdriving, set the collar to the desired setting. If
you do not yet know the appropriate setting, proceed as
follows:
• Set the collar to the lowest torque setting.
• Tighten the rst screw.
• If the clutch ratchets before the desired result is
achieved, increase the collar setting and continue
tightening the screw.
• Repeat until you reach the correct setting.
• Use this setting for the remaining screws.
Dual range switch - gure E
The dual range feature of your drill allows you to shift gears
for greater versatility.
• To select low speed, high torque setting (position1), turn
tool off and permit to stop. Slide gear shifter button (4)
away from the chuck.
• To select the high speed, low torque setting (position 2),
turn tool off and permit to stop. Slide gear shifter button
back toward the chuck.
Note: Do not change gears when tool is running. If you are
having trouble changing gears, make sure that the dual range
gear button is either completely pushed forward or completely
pushed back.
Keyless chuck - gure F
Warning! Make certain the battery pack is removed to prevent
tool actuation before installing or removing accessories.
To insert a drill bit or other accessory:
• Grasp the chuck (5) and rotate it in the counterclockwise
direction, as viewed from the chuck end.
• Insert the bit or other accessory fully into the chuck, and
tighten securely by rotating the chuck in the clockwise
direction as viewed from the chuck end.
Warning! Do not attempt to tighten or loosen drill bits (or any
other accessory) by gripping the front part of the chuck and
turning the tool on. Damage to the chuck and personal injury
may occur when changing accessories.
Screw driving
• For driving fasteners, the forward/reverse button should
be pushed to the left.
• Use reverse (button pushed to the right) for removing
fasteners.
Note: When moving from forward to reverse, or vice versa,
always release the trigger switch rst.
