9
ENGLISH
Drilling
• Use sharp drill bits only.
• Support and secure work properly, as instructed in the
Safety Instructions.
• Use appropriate and required safety equipment, as
instructed in the Safety Instructions.
• Secure and maintain work area, as instructed in the
Safety Instructions.
• Run the drill very slowly, using light pressure, until the
hole is started enough to keep the drill bit from slipping
out of it.
• Apply pressure in a straight line with the bit. Use enough
pressure to keep the bit biting but not so much as to stall
the motor or deect the bit.
• Hold the drill rmly with two hands, one hand on the
handle, and the other gripping the bottom around the
battery area or the auxiliary handle if provided.
• DO NOT CLICK THE TRIGGER OF A STALLED DRILL
OFF AND ON IN AN ATTEMPT TO START. THIS WILL
RESULT IN DAMAGE TO THE TOOL.
• Minimize stalling on breakthrough by reducing pressure
and slowly drilling through the last part of the hole.
• Keep the motor running while pulling the bit out of a
drilled hole. This will help reduce jamming.
• Make sure switch turns drill on and off.
Drilling in wood
Holes in wood can be made with the same twist drill bits used
for metal or with spade bits. These bits should be sharp and
should be pulled out frequently when drilling to clear chips
from the utes.
Drilling in metal
Use a cutting lubricant when drilling metals. The exceptions
are cast iron and brass which should be drilled dry. The cutting
lubricants that work best are sulphurized cutting oil.
Drilling in masonry
For drilling in masonry, set the collar (3) to the hammer
drilling position by aligning the symbol with the marking. Use
carbide tipped masonry bits. Refer to Drilling section. Keep
even force on the drill but not so much that you crack the
brittle material. A smooth, even ow of dust indicates the
proper drilling rate.
LED work light
When drill is activated by pulling the trigger switch (1), the
integrated LED work light (8)will automatically illuminate the
work area.
Note: The work light is for lighting the immediate work surface
and is not intended to be used as a ashlight.
Bit tip storage
A bit storage slot (9) is built into the base of the tool.
Troubleshooting
Problem Possible cause Possible solution
Unit will
not start.
Battery pack not
installed properly.
Battery pack not
charged.
Check battery pack
installation.
Check battery pack
charging requirements
Unit starts
immedi-
ately upon
inserting
battery
The switch has
been left in the
“on” position.
The switch must be
moved to “off” to prevent
the tool from imme-
diately starting when
battery is inserted.
Battery
pack will
not charge.
Battery pack
not inserted into
charger.
Charger not
plugged in.
Surrounding air
temperature too
hot or too cold.
Insert battery pack into
charger until LED lights.
Plug charger into a
working outlet.
Move charger and
battery pack to a sur-
rounding air temperature
of above 40 degrees
F (45ºC) or below 105
degrees F (+40.5ºC)
Unit
shuts off
abruptly.
Battery pack
has reached its
maximum thermal
limit.
Out of charge.
(To maximize
the life of the
battery pack it
is designed to
shutoff abruptly
when the charge
is depleted
Allow battery pack to
cool down.
Place on charger and
allow to charge.
