14 ► SD67 User Manual
Capacity (Spike Head).................................................................................................................1.9 in dia/4.8 cm dia
Pressure Range Nominal ................................................................................................................. 1500 psi/103 bar
Pressure Range Max ........................................................................................................................ 2500 psi/172 bar
Blows Per Minute....................................................................................................................................1300 to 1800
Maximum Back Pressure...................................................................................................................... 250 psi/17 bar
Flow Range ............................................................................................................................... 7–10 gpm/26–38 lpm
Porting ...................................................................................................................................................-8 SAE O-ring
Couplers ..........................................................................................HTMA/EHTMA Flush Face Type Male & Female
Connect Size and Type .......................................................................................................3/8 in. Male Pipe Adapter
Hose Whips ........................................................................................................................................................... Yes
Weight
Anti-Vibration Handle Model ..................................................................................................................67 lbs/30 kg
Anti-Vibration Handle w/ Extended Foot Model.....................................................................................68 lbs/31 kg
Overall Length – Standard Foot .......................................................................................................... 25.25 in/64 cm
Overall Length – Extended Foot .......................................................................................................... 28.75 in/73 cm
Overall Width – Anti-Vibration Handle ................................................................................................... 16 in/40.6 cm
Maximum Fluid Temperature .................................................................................................................. 140 °F/60 °C
EHTMA Category............................................................................“C” (20 lpm@ 138 bar) or “D” (30 lpm@ 138 bar)
Noise Level .................................................................................................................................................... Lwa 106
Vibration Level .............................................................................................................................................. 20.0 m/s
2
ACCESSORIES (SECONDARY FOOT & CUPS)
Special spikes listed below may require the use of a special spike drive foot with changeable
cups. Order spike drive foot based on model.
Stanley recommends that this change be
performed by a authorized service center.
Spike Driver Foot (Standard) for screw on cups (Models SD67101, SD67101B) .............................................23342
Spike Driver Foot (Extended) for screw on cups (Models SD67141, SD67141B).............................................28206
Dome Head Spike Cup ......................................................................................................................................25525
Hairpin Cup........................................................................................................................................................23345
Cutspike Cup ..................................................................................................................................................... 23344
SPECIAL TOOLS
O-ring Tool Kit .................................................................................................................................................... 04337
Split Rings (Used with 04910) ...........................................................................................................................04908
Spacer ...............................................................................................................................................................04909
Flow Sleeve Removal Tube (Used with 04908 & 05508) .................................................................................. 04910
Accumulator Disassembly Tool (Used with 04910) ...........................................................................................05508
Accumulator Cylinder Puller ..............................................................................................................................05640
Accumulator Plug Wrench .................................................................................................................................29135
Sleeve................................................................................................................................................................30939
Collet 7/8 inch ....................................................................................................................................................30956
Flow Sleeve Kit (See page 16 for parts included in kit) ..................................................................................... 74396
SPECIFICATIONS
