Stanley SD67 User Manual

16 ► SD67 User Manual
MODEL DESCRIPTIONS
SD67101 & SD67101B: Anti-Vibration Handles and
Standard (Short) Solid Foot.
SD67141 & SD67141B: Anti-Vibration Handles and
Extended (Long) Solid Foot.
Item P/N Qty Description
1 00293 1 O-RING *
2 01362 1 O-RING *
3 02494 2 HANDLE GRIP
4 03972 1 COUPLER FEMALE(SEE NOTE)
5 03973 1 COUPLER MALE (SEE NOTE)
6 04054 2 O-RING *
7 04055 1 WASHER
8 04056 1 ROD WIPER*
9 04058 1 COMPRESSION COIL SPRING
10 04062 1 BACKUP WASHER
11 04063 1 ROD SEAL *
12 04064 1 SEAL RETAINER WASHER
13 04065 1 AUTOMATIC VALVE
14 04066 1 AUTOMATIC VALVE BODY
15 04067 4 PUSH PIN
16 04068 1 FLOW SLEEVE TUBE
17 04069 1 FLOW SLEEVE (SEE NOTE)
18 04070 1 PISTON
19 04071 4 SIDE ROD
20 04073 1 O-RING*
21 04074 1 ROD WIPER*
22 04075 4 SIDE ROD NUT
23 04571 2 PUSH PIN
24 04795 2 O-RING*
25 06891 1 O-RING*
26 07493 1 O-RING PLUG MALE MODIFIED
27 07628 4 HHCS 1/4-20UNC X .625
28 07890 1 ROLL PIN 3/16 O.D. X 1.500 LG.
29 12832 1 ORIFACE PLUG
30 13837 1 SEAL WASHER
31 74832 2 STANLEY LOGO
32 15419 1 SEAL CARRIER
33 15420 1 RAM (USED WITH SPIKE DRIV-
ER FOOT (73322)
28207 1 RAM EXTENDED (USED WITH
SPIKE DRIVER FOOT 73187)
34 73322 1 SPIKE DRIVER FOOT SOLID
73187 1 SPIKE DRIVER FOOT
EXTENDED SOLID
35 16732 1 O-RING *
36 20498 2 COMPRESSION COIL SPRING
Item P/N Qty Description
37 20499 1 CHARGE VALVE
38 20500 2 ROLL PIN 1/4 O.D. X 1.000 LG.
39 20502 1 CAST TRIGGER
40 20508 2 PIVOT SCREW
41 20511 1 LEVER
42 20515 1 VALVE SPOOL
43 20541 2 COMPRESSION COIL SPRING
44 24067 1 RETAINING RING
45 73680 1 RAILROAD HELP DESK DECAL
46 26448 1 SPACER
47 26449 1 ACCUMULATOR PLUG
48 26450 1 TOP PLATE
49 26451 1 BUSHING
50 26452 1 SINTERED FILTER
51 26574 1 DIAPHRAGM 4.210 DIA
52 26596 1 ACCUMULATOR VALVE BLOCK
53 28369 1 HANDLE (GUARDED)
54 31067 1 SPACER PLUG
55 34127 1 CUP SEAL
56 44873 1 COMPRESSION COIL SPRING
57 56725 2 HOSE ASSY RAILROAD 18"
58 58529 1 TRIGGER HANDLE
59 66727 2 HOSE ASSY
60 73025 2 FILLER SNAP-ON LARGE
61 74670 1 NAME TAG-SD67
04596 1 SEAL KIT (INCL PARTS W/*)
NOTE: SEE BELOW FOR COUPLER AND HOSES FOR
EACH MODEL.
SD67101 & SD67141 (Couplers 03972 & 03973) Set P/N-
03971, Hose Assy P/N-56725
SD67101B & SD67141B (Couplers 47436 & 47437) Set
P/N-47438, Hose Assy P/N-66727
SD67 PARTS LIST
NOTE: There is a ow sleeve kit available P/N-74396 that
includes: item # 6 (Qty-2 04054 o-ring), item # 15 (qty-
4 04067 push pin), item # 17 (qty-1 04069 ow sleeve),
item # 20 (qty-1 04073 o-ring) and inst sheet 74398.
