Stanley SPL31A-N - Parts List

SPL31 User Manual ◄ 15
ITEM P/N. QTY. DESCRIPTION
2 00596 4 CAPSCREW
3 00138 1 O-RING* (PART OF SEAL KIT)
4 00664 2 RETAINING RING
5 01211 1 O-RING* (PART OF SEAL KIT)
7 03972 1
COUPLER,FEMALE 3/8NPT
FL.FACE SET P/N-03971 (SP-
L31A AND SPL31A-S ONLY)
81158 1
COUPLER,FEMALE 3/8NPT
FL.FACE SET P/N-81160 (SP-
L31A-N ONLY)
8 03973 1
COUPLER,MALE 3/8NPT
FL.FACE SET P/N-03971 (SP-
L31A AND SPL31A-S ONLY)
81159 1
COUPLER,MALE 3/8NPT
FL.FACE SET P/N-81160 (SP-
L31A-N ONLY)
9 04911 1 O-RING* (PART OF SEAL KIT)
10 08015 2
BACK-UP RING* (PART OF
SEAL KIT)
11 09275 2 RETAINING RING EXTERNAL
18 25992 1 JAW PIVOT SLEEVE
19 26388 2
SPRING CUP* (PART OF SEAL
KIT)
20 26812 2 RETAINING RING EXTERNAL
22 32094 1
ROD WIPER* (PART OF SEAL
KIT)
23 32097 1 COMPRESSION COIL SPRING
24 81156 2 GRIP JAW CASTING
27 56725 2
HOSE ASSY (SPL31A and
SPL31A-S ONLY)
66727 2 HOSE ASSY (SPL31A-N ONLY)
28 71942 1 CHECK VALVE
29 72537 1 SPL31 AUX HANDLE
30 72538 1 PISTON INSERT
31 72540 4 CAPSCREW
32 73044 1
CHUTE, SUB-ASSY (INCLUDES
PAINT & DECALS)
33 72552 1 ALUMINUM WASHER
34 72554 1
EXTERNAL INVERTED RET
RING
36 72853 1 JAW PIN
37 72854 1 OIL TUBE
SPL31A / SPL31A-N / SPL31A-S
ITEM P/N. QTY. DESCRIPTION
38 72883 1
SPL31A ROD ASSEMBLY (IN-
CLUDES ITEM 55)
39 72884 1
LOWER CYLINDER HEAD
(INCLUDES BEARING & HELI-
COILS)
40 73045 1
CYLINDER, SUB-ASSY (IN-
CLUDES PAINT & DECALS)
43 72892 4 WASHER
44 72894 1 COMPRESSION COIL SPRING
45 72895 1
PISTON ROD SEAL* (PART OF
SEAL KIT)
46 72897 2 O-RING* (PART OF SEAL KIT)
49 73043 1
SPIKE PULLER HANDLE WITH
EXPANDER PLUGS INSTALLED
(SEE PAGE 13 FOR PARTS)
50 73010 1
C SHAFT RINGS* (PART OF
SEAL KIT)
55 72535 1
PISTON SEAL* (INCLUDED
WITH ITEM 38 AND ALSO PART
OF SEAL KIT)
56 81565 2 GUIDE HALF
SK1 73042 1
SEAL KIT (* DENOTES PART IN
SEAL KIT)
PARTS LIST
