1. Main microphone input: XLR connector
2. Microphone 2 input: 1/4” connector
3. Mic level controls: Controls the overall microphones output level
4. Mic EQ: Controls for low frequency, midrange, and high frequency
equalization of both microphones with (+/-12 dB) Note: Any changes made to
EQ settings will change the overall microphone output level
5. Effect ON/OFF switches: Turns effect send signal ON or OFF for each channel
6. Cue ON/OFF switches: Turns Cue signal ON or OFF for each channel
7. Input selector switches: Selects the audio signal source for each channel
8. Gain control: Controls the input sensitivity of each channel
9. EQ: Individual controls for low frequency, midrange, and high frequency
equalization with (+9/-26 dB) Note: Any changes made to EQ settings will
change the overall output level
10. Pan control: Controls left/right output balance of each channel
11. Channel faders: Controls the output level of each channel
12. Crossfader Reverse: Reverses the direction of the crossfader
13. Frequency Kill switches: Individual kill controls for low frequency, midrange,
and high frequency of channels 1 and 3
14. Crossfader: Fades the master output between channels 1 and 3.
15. Headphone output: Connection for 1/4 inch headphone. It is recommended
headphones with an impedance rating of 200 ohms or less be used for
maximum volume
16. Headphone level control: Controls the overall headphone output level. It is
recommended headphones with an impedance rating of 200 ohms or less be
used for maximum volume
17. Master Cue ON/OFF: Turns headphone output ON or OFF
18. Master level control: Controls the overall signal output level.
19. Master balance control: Controls left/right output balance of the
overall signal
20. Send level: Controls the level of the signal traveling to the external effects
unit used in the effects loop
21. Return level: Controls the overall level of the the external effects used in the
effects loop
22. Power indicator: Blue LED indicates whether mixer is ON or OFF
23. Level meter: Displays the level of the overall output stereo signal
24. Power switch: Turns the mixer "ON" or "OFF"
D E S C R I P T ION OF FU N C TI O N S
