STAR MANUFACTURING
265 Hobson St., Smithville, Tennessee U.S.A.
(314) 678-6303
www.star-mfg.com
Parts List January 07, 2015, Rev. D
Model: PSC14D Split Lid Two Sided Grill
Fig No. Part Number Quantity Description Application
40
D9-GR0629
1
CNTRL PROG.,TACO BELL
PSC14DTB-120V, -CUL, 208V,
240V
D9-GR0630 CNTRL PROG., DEL TACO PSC14DDT
D9-GR0635 CNTRL PGM., TACO BELL, 230 PSC14DTB-230V, JPN
D9-GR0647 CNTRL PGM (PSC14DK-UK) PSC14DK-UK
D9-GR0658 CNTRL PROG. (PSC14DK-120) PSC14DK-120
41 2K-Z1971 8 SPACER .257X.75X.25 NYLON
42 2E-Z3808 1 SWITCH(EATON)-30A@120V,
43
2M-Z15638
1
OVERLAY, TACO BELL PSC14DTB
2M-Z15853 OVERLAY, STANDARD PSC14DDT, PSC14DK
44 Z1-70-07-0343 1 SWITCH GUARD
45 2M-12-07-0038 1 LABEL ON & OFF
46 2I-05-07-0013 1 BOOT SWITCH
47 2A-Z11582 2 PLATE, HINGE MECH MOUNT
48 2R-Z3345 1 COUNTER BALANCE-SPLIT TOP
49 2C-Z2593 4 10-24x1 1/2 SL HX/W NP
50 2E-Z2894 1 TERMINAL BLOCK (304)
51
2E-05-07-0351
1
TRANSFORMER 115/10V 6VA 120V, CUL
2E-05-07-0350 TRANSFORMER 230V/10V 6VA 230V, UK, 208V, 240V
52 2E-Z3335 3 RELAY DBL POLE-SNGL THROW
53 2C-6260 8 WASHER #10 INT STL PSC14DDT-120
54 2V-Z3072 2 HANDLE-SIDE PSC14DDT-120
55 D9-Z18465 4 BRACKET, HANDLE SPLIT PSC14DDT-120
56 2C-1522 4 SCREW 1/4-20X.5 STL PSC14DDT-120
NP 2C-8833 1 SCREW 8-18X1/2 HEX STL
