Star Pro-Max PSC14D - Parts List; Part Number and Description

SK2678: PSC14D Tabletop Split Lid Two-Sided Grill
Parts List
Model: PSC14D Split Lid Two Sided Grill
Fig No. Part Number Quantity Description Application
1
2E-Z16762
1
CONDUIT AY., RIGHT
2E-Z16763 CONDUIT AY., LEFT
2 2I-Z14209 2 O-RING
3 2F-Z16425 2 HOUSING,CONDUIT
4 2C-Z2992 8 BOLT 1/4-20X1 PHP STL NP
5 2C-08-07-0262 8 WASHER, SS 1/4 INT-LOCK
6 2C-08-07-0040 12 NUT 1/4-20 ACHD STL NP
7
2V-Z16435 2 AY.,HANDLE,ARM & BURN GD
2V-Z18619 2 ARM ASSY., SPT, NO BURN GUARD PSC14DDT
8 2C-Z3200 4 PIN - TOP HOUSING
9
D9-GR0624
1
WELD AY.,LEFT TOP HOUSING
D9-GR0625 WELD AY.,RIGHT TOP
10 2C-Z5883 27 10-24 X 1/2 FZA SCREW
11 2C-Z2899 4 5/16-18UNC TOPLOCK L/NUT
12 2C-1827 13 WASHER #10 EXT STL NP
13 2C-1512 12 SCREW 10-24X3/8 RHP STL
14 2C-Z2893 26 NUT 10-24 HEX STL ZP
15 D9-Z13013 4 BRACKET, INSULATION HOLD
16 D9-Z2133 2 INSULATION FIBERGLASS TOP
17 D9-Z13011 2 PLATE-TOP ELEMENT RET.
18
2N-Z9325
2
ELEMENT 500 WATT 120V SPT 120V, CUL
2N-Z9326 ELEMENT 500 WATT 240V 208V,230V, 240V, UK, JPN
19 2C-08-07-0285 12 SCREW 10-24X3/4X3/8 TYPE
20 2F-Z16421 2 CASTING,14ST,SM,POL.
21 2C-2853 2 SCREW #8 5/8 A THP STL NP
22 2C-Z3350 3 HALF CLAMP .188 D STL ZP
23 2E-Z3278 2 RTD PROBE - 48” LONG WIRE
24 D9-Z3903 2 BRACKET, PROBE MOUNT
25 2F-Z17603 1 CAST.ALSM14B,.44SPL,POL.
26 2E-Z1470 1 SENSOR-RTD 2000 OHM
27 D9-Z12027 1 PROBE BRACKET - BOTTOM
28
2N-Z9324
1
ELEMENT 1300WATT 120V-14B 120V, CUL,
2N-Z9327 ELEMENT 1300WATT 240V-14B 208V, 230V, 240V, JPN
29 D9-Z13338 1 ELEMENT & INSULATION PLT
30 D9-Z2888 1 INSULATION - 14”
31 D9-Z12885 2 INSULATION HOLD DOWN,
32
2E-Z4119
1
POWER CORD, 12/3, 5-20P 120V, CUL
2E-Y9253 INLET IEC 320 16 AMP 230V, UK
2E-Z2905 CORD SJTO 12/3 NEMA 6-20P JPN
2E-Z9192 CORDSET (DETACHABLE) UK
2E-Z19809 CORD SET L5-30, 12/3, 6FT PSC14DKL-CUL
D9-GR0193
POWER CORD ASSY
CUL
D9-GR0194 208V, 240V
33 2K-Y6764 1 BUSHING - STRAIN RELIEF
34 D9-GR0588 1 GREASE DRAWER ASSY.
35 2C-6349 4 SCREW #8X3/8 B THP STL NP
36 2A-Z11501 4 FOOT 1” SOLID RUBBER
37
D9-GR0628
1
BASE & GRS CAB,4”TLL BDY 120V, CUL
D9-GR0634 BS & GRS CAB, 4”TLL BDY230 230V, UK
38 2C-Z2594 18 NUT 6-32 HEX W STL NP
39 2K-08-07-0004 8 SPACER ROUND NYLON
