5-3. Installing the Roll Paper Guide
When using paper roll with 57.5 mm or 69.5 mm width, install the attached roll paper guide
in the groove in the printer. The setting for memory switch 2-A and 2-B must be changed to
change the print width.
For instructions on setting the memory switch, please refer to the separate Specification Man-
ual.
69.5 mm width
Roll paper guide
57.5 mm width
Roll paper guide
