SF-HC25C3 Height Controller
5
It is integration starting arc successful judgment function, and arc successful
feedback function.
2.2 Functional features
Automatic initial positioning
real-time arc voltage feedback.
input logic level can be set freely.
two-speed initial alignment.
manual, automatic, positioning of the up and down speed can be set respectively.
Grade 255 l Pwm output, adjustable speed, precise control of motor speed,
several current setting, short circuit protection.
all input and output adopt photoelectric isolation, plasma voltage feedback using
linear photoelectric isolated, independent power supply, can very good
compatibility with the partial pressure of various brands of imported plasma
power supply.
integration and arc successful judgment function, and arc successful feedback
function.
L set elements linking piece, without special shielding box.Plasma power supply
on the back of the terminal control all meet in this controller, convenient
connection.
all interfaces using pluggable terminal, don't need welding.
built-in software calibration pressure ratio.
self-learning function, use the fool, convenient debugging and use.
2.3 Main technical indicators
Power supply requirements: DC24V + / - 10% 3A
Suitable motor: 24V with DC motor
