PKG08804-UM128 11
ENGLISH
NOTE
These instructions refer only to "in field" adjustments
which may be performed by the operator without
affecting or impairing gage performance. Adjustments
or repair other than what is covered above should be
done by either factory or factory authorized personnel.
Failure to do so could possibly result in gage damage
and loss of measurement integrity.
01234567890
Figure 1
128 Combination
Head Master 10.XXXX
Note: Set-up vertically
this end down
Sweep Side
to Side
Sweep Fore
and AFT
1.000" (25mm)
Micrometer Setting
(mid-range)
Micrometer
Spindle Lock
128 Combination
Head and Master
with Size Marked
Threaded Plug
(Bezel Locking
Screw Underneath)
Base
(Zero Reference)
Housing
To Next Page
