3. System Specifications
Feature
MVR200
MVR300
Measurement Range, X-Y-Z
200 x 100 x 200 mm (8” x 4” x 8”)
300 x 200 x 200 mm (12” x 8” x 8”)
Unit Dimensions, H x W x D
865 x 600 x 645 mm
(34” x 23.7” x 25.4”)
865 x 790 x 865 mm
(34” x 31” x 34”)
Metrology Base
Granite
Reading Resolution, X-Y-Z
0.5 µm (0.00002”)
Reading Accuracy, X-Y-Z
Accuracy: 1.9 µm + 5L/1000 for X and Y, 2.5 µm + 5L/1000 for Z
Motion Control
Manual X and Y, motorized Z
Substage Illumination
LED illumination matched to camera optics
Surface Illumination
LED ring light
Camera Resolution
1 MP ( 1024 x 768 pixels) for basic models with dedicated zoom optics
2 MP (1620 x 1236 pixels) for models with bayonet lens mount
Image Update Rate
15 frames/sec, including image processing
Computer Hardware
All-in-one PC with 55 cm (21.5”) color touch screen, 4 GB RAM
Computer Interfaces
Ethernet (1 GB/sec), Wi-Fi, four USB 2.0 ports
Data Storage
500 GB hard disk
Operating System
Windows
®
7 Professional
Application Software
MetLogic M3 metrology software and DXF/FOV option pack
Geometrical Constructs
2D geometries plus height
Comparison to CAD Files
DXF CAD file import, automatic comparison to CAD files
Operator Controls
Computer touch-screen, keyboard with integral touchpad
Optics Mounting
Fixed mount or bayonet fitting for quick optics changes
Power for Metrology Unit
“Brick” type AC adapter, 100/240 Vac input, 24V, 5A output
Power for All-in-One PC
“Brick” type AC adapter, 100/240 Vac input, 19.5V, 7.9A output
Zoom Optics
6.5:1 Zoom
Magnification on CCD
0.70X to 4.50X
Field of View Width
10 to 1.6 mm (0.39” to 0.06”)
Magnification on Monitor
31X to 200X
Zoom Working Distance
88 mm
Available Auxiliary Lenses
0.5X, 1.5X, 2.0X
Telecentric Optics
0.30
0.50
0.80
1.0
2.0
4.0
Magnification on CCD
0.30X
0.50X
0.80X
1.0X
2.0X
4.0X
Magnification on Monitor
13X
22X
36X
45X
89X
178X
Field of View Width
24 mm
0.93”
14 mm
0.56”
8.9 mm
0.35”
7.1 mm
0.28”
3.6 mm.
0.14”
1.8 mm
0.07”
Optical Distortion (ΔH/H)
0.003%
0.018%
0.009%
0.003%
0.006%
0.005%
Telecentric Working Dist.
110 mm
* At 1:1 pixel setting
