Awareness Technology, Inc. Stat Fax 303 Plus Operator’s Manual Rev. J 9
1.6 Major Parts and Controls
The following labeled sketches will help you to locate and identify the major parts of the
microstrip reader. More details on the operation of each feature are provided in section 2,
Operating Procedures. The voltage select switch is on the base. The power switch and serial
connector are on the rear panel.
Cover
Optical system
(under cover)
Printer paper well
(with paper roll cover)
Printer paper slot
Alpha-numeric display
Carrier track
(with carrier)
Keyboard
Place carrier groove
over bar
