Page 28
The Biosystem Archive Series which have revolving turntables are factory set to fill to the levels shown below.
Because the turntable is a sealed unit this means that these are all vapour phase settings. Other settings
including liquid phase are available upon request.
BM36
9916063
BM40
9916082
BM55
9916047
BM60
9916083
BM80
9916049
BM100
9916084
BM100+
9916088
DIM A (mm) 405 405 355 355 355 355 355
HIGH LEVEL VOL (L) 184 193 225 236 260 281 300
LOW LEVEL VOL (L) 159 168 172 183 207 228 247
VOL PER FILL (L) 25 25 53 53 53 53 53
A-3
