6
• Remove the Filter from the appliance by
pressing the lock catch.
• Remove the stainless steel frame by
unscrewing the four screws (M4*10).
• Remove the screws (ST4*12) on the lid of the
terminal box, and disconnect the wires to the
control panel.
• Disconnect the wires to the light connectors.
• Fasten the appliance to the cabinet by using
the 12 screws (ST4*20).
• Replace the stainless steel frame and secure
with the removed four screws (M4*10).
Min. 650mm
497mm
13mm
259mm
150mm
410mm
256mm
245mm
284mm
492mm
520mm
To Next Page
