Statesman CH53SS - Appliance Overview; Installation

5
APPLIANCE OVERVIEW
Lights
INSTALLATION
This appliance should only be installed by a qualied engineer. Ensure all that all masonry work
has been completed before installing the appliance and that there is enough space between the
appliance and the top of the cooking surface.
Important: Before installation, it is important to decide whether this cooker hood will be used in
extraction mode or recirculation mode.
If the extractor is to be ducted out, ensure that it is possible to connect the ducting hose.
If the extractor is to be used in recirculation mode, ensure that two carbon lters are tted on to the
hood and the canopy allows the recirculating air to be circulated from the top of the extractor and
canopy.
Carbon Filters are optional extras, they are available to be purchased from Statesman Spares
Department.
Carbon Filters are neither washable nor reusable.
Control Panel
Main Body
Grease Filter
Motor
Extraction Mode Recirculation Mode
Carbon Filter
