Statesman ECH77TC - Operating Instructions; Basic Hob Operation

8
• The cable must be checked regularly and only replaced by a properly qualied technician.
• Ensure the appliance is connected to an isolating switch providing full disconnection from the
mains supply. The appliance must not be connected to the mains supply by means of a 13A
plug and socket.
• The qualied technician must to use a H05GG-F power cord.
OPERATING INSTRUCTIONS
The controls respond to touch, so you do not need
to apply pressure and for best response use the ball
of your nger, not the tip. (Fig. 8)
Fig 8.
1. Switch on at the mains supply, the appliance will
beep once and the indicators will show for
1 second. This indicates that the appliance has
entered “Stand By” mode.
2. Touch the ON/OFF Control , all indicators will
show “-” (Fig. 9).
3. Place a suitable pan on the cooking zone
required, ensuring the cooking zone and pan are
clean and dry (Fig. 10).
4. Touch the required Heating Zone Control.
Fig 9.
Fig 10.
5. Adjust the heat setting by touching and sliding the
Slider Control to the required setting (Fig. 11).
6. To switch o a cooking zone, touch the required Heating
Zone Control (Fig. 12).
7. Touch and slide the Slider Control to Setting “I“and ensure
the display shows “0” (Fig. 13).
Fig 11.
Fig 12.
Fig 13.
