Staubli MC4 - Product Specification and Mating Correlation

7 / 8
Tab. 1 TÜV Rheinland
MC4 MC4-Evo 2
类型
Type
PV-KST4/*-UR PV-KST4-EVO 2/*-UR
PV-KBT4/*-UR PV-KBT4-EVO 2/*-UR
额定电压 IEC
Rated Voltage IEC
DC 1000 V DC 1500 V
额定电流 IEC
Rated current IEC
22 A (2,5 mm²) 39 A (2,5 mm²)
39 A (4 mm²) 45 A (4 mm²)
39 A (6 mm²) 53 A (6 mm²)
45 A (10,0 mm²) 60 A (10,0 mm²)
温度上限 (ULT)
Upper limit temperature (ULT)
105 °C 115 °C
Tab. 2 UL
MC4 MC4-Evo 2
类型
Type
PV-KST4/*-UR PV-KST4-EVO 2/*-UR
PV-KBT4/*-UR PV-KBT4-EVO 2/*-UR
额定电压 UL
Rated Voltage UL
DC 1500 V DC 1500 V
额定电流 UL
Rated current UL
30 A (AWG14) 28 A (AWG14)
35 A (AWG12) 39 A (AWG12)
50 A (AWG10) 45 A (AWG10)
50 A (AWG8) 50 A (AWG8)
最高工作温度 (MOT)
Max. operating temperature (MOT)
85 °C 85 °C
连接经认证的产品规格
Product Specification in relation to certified mating
correlation
电流及电压额定值以及温度上限仅限于 Stäubli 相应的配接连接
器。详细规格请见下方表 1 和 表 2。
The current and voltage ratings, as well as the upper limiting tem-
perature is limited to the corresponding mating connector from
Stäubli� For detailed specification refer to Tab� 1 and 2 below�
(Tab. 2)
考虑到校正系数，根据国家电气法规（NEC）针对户外应用的要求，
这些产品的额定载流量受导线尺寸的限制。
(Tab. 2)
The ampacity rating of these products is limited based on the wire
size used per the National Electrical Code (NEC) requirements for
outdoor applications considering the correction factor�
