SETUPANDPROGRAMMING
Whenthecameraisfirstturnedon,theinternalLCDscreendisplays
thecamerastatus.Thefollowinginformationispre sentonthisscreen.
(POSSEMODE) (CUSTOM–PIRMODE)(CUST OM–TIMELAPSEMODE)

Ifnobuttons are pressed after 30 seconds the LCDscreenwillpower
downtoconservebatterylifeandenter1minutecountdowntoenter
PIR detection mode.To re‐power the display screen, press and hold
theUPorDOWNbuttonuntilyouseethestatusscreen.
Definition
• DayandTime:Displaysthedateandtimethatyouhaveset.
• Operationmode:
¾ PIR:CameratakesImage/VideoperPIRtrigger.
¾ TimeLapse(tLS):Cameratakesthestillimageperpresettime.
• CapturingSequencemode:
¾ 1P‐9P:1to9burstmodeimagecapturingper
PIRtrigger.
¾ Video:10to180secondsadjustablevideoperPIRtrigger.
• ResolutionforImages:ColorDaytime/Black&WhiteNighttime
¾ 3Stars(8Mp):Selectthisoptiontocapturean8.0Mpixels
image.(Highimagequality)

www.stealthcam.com
Toll Free 877-269-8490
14
¾ 2Stars(5Mp):Selectthisoptiontocapturea5.0Mpixels
image.(Lowimagequality)
¾ 1Star(3Mp‐Default):Selectthisoptionto
capturea3.0Mpixelsimage.(Baseimage
quality)
• ResolutionforVideo:ColorDaytime/Black&WhiteNighttime
¾ VGA:640x480*ONLYresolution*
•
Timeout:Tosettheamountoftimeinminutes&secondsthe
camerawillsleepbetweenPIRtriggering.
• Moonphase:Displaysthemoonphases.
• Tempstamp:Tempe rat urestampwilldisplayonstillimagesand
firstframeonlyonvideofiles.
• Zoom:Digitalenhancementtodifferentzoomlevel.

¾ 1X:Normal–theword“ZOOM”willnotdisplay.
¾ 2X:Twotimeszoom–theword“ZOOM”willdisplay.
¾ 4X:Fourtimeszoom–Theword“ZOOM”willblink.
• BatteryStatus:Showsthebatterystatus.
¾ Full:Thebatteryisfull.
¾ Low:Thebatteryis
low.
(FrontLowBatteryindicatorwillalsoblink.)
NOTE:Whenthecameradetectslowbatteries,thecameraunitwill
poweroffwithin30secondsautomatically.Pleasereplacewithnew
batteries;otherwisethecameramaynotworkproperly.
www.stealthcam.com
Toll Free 877-269-8490
15
SettingtheProgramSelectionMode:
ThiscameraisequippedwithaProgramselectiontoggleswitch.Make
surecameraisintheOFFpositionbefor emakinganychanges.
• CUSTOM–Thisallowsuserstodefinewhatsettingthecamerawill
use.
• POSSEMODE–Thisbypassesalluserdefinedsett ingsanduses
thefollowingsettings:
(PIR
mode/5MPResolution/2PBurst/1minTime‐Out/1xZoom)













www.stealthcam.com
Toll Free 877-269-8490
16
SettingtheCamera’sOperationMode:
YourStealthCamcanbeprogrammedtooperationeitherinPIR
DetectionmodeorTimeLapsemode.
NOTE:MakesuretheProgramControlSwitchissettothe“CUSTOM”
position;otherwise,youcannotentertheMenuProgrammodetoset
thecameraineitherPIRorTimeLapseMode.
• SwitchthecameratotheONposition.
¾ LCDscreenwilldisplaythecamerastatusscreen.
• Pressthe[MENU]buttononcewithin30secondstoenterthe
programmingmode,thewordPIRortLSwillbeblinking.





• Pressthe[UP]or[DN]buttontoselect
thePIRortLS.
• Press[OK]tosaveyourselection.
• Press[MENU]buttontoexit.





